P12 mobile led displays screens

Product name: P12 mobile led displays screens

Keywords:P12 mobile led displays screens

led displays led modules sales factory:Apollo mobile:008615875527577 MSN or Email:[email protected]

P12 mobile led displays screens
SINOLIGHT P12 LED Display [Pitch 12mm] is equipped with Virtual Pixel Function that produces excellent image quality and color detail. It is IP Certified and is highly recommended for outdoor use. A slim and solid design with easy to install cabinet, coupled with a new and enhanced operating system, the P12 is well-suited for Exhibition & Entertainment, Commercial & Advertising and Professional Sports Display markets.

Parameter  Unit  Value
Brightness  nits  6000
Colour temperature  deg. K  5,000-9,000
Viewing angle - Horizontal (50% brightness)  deg. 110 (+55/-55)
Viewing angle - Vertical (50% brightness)　 deg. 50 (+25/-25)
Panel weight kg  53
Panel width  mm  1152
Panel height  mm  768
Panel depth  mm  150
Panel area  sq. m.  0.885
Panel material   Epoxy paint coated Aluminum/Steel
Ingress protection (front/rear) IP  IP65/54
Operating temperature range deg. C  -40to +65
Pixel type and configuration  R/G/B  Oval Lamp,2R/1G/1B
Pixel pitch  mm  12
Pixel matrix per panel    96X64
Pixels per panel    6,144
Pixels per sq. meter    6,944
Recommended minimum viewing distance  m  12
Colours    4.4 trillion
Grey scale (linear)  Levels  16384 levels per colour
Brightness control Levels  100%
Processing depth bit  10
Video frame rate  Hertz  60-85
Display refresh rate Hertz  240-1000
Drive mode   Dynamic 1/2 Duty Constant Current
Input voltage (nominal)  VAC  AC90-260V
Input power frequency  Hertz  50 - 60
Input power (max) Watts  1000
Input power (ave.) Watts  350
Lifetime (50% brightness)  Hours  ≥100,000
Red wavelength (dominant) nm  620~630
Green wavelength (dominant)  nm  515~530
Blue wavelength (dominant) nm  465~475
Data interconnection   LAN　Line
Application   Rental/fixed installation
